Bingfu Quad-System GNSS Antenna - High-Gain 28dB LNA, IP65 Waterproof, GPS/BeiDou/GLONASS/Galileo/QZSS/SBAS, SMA Male Connector for Automotive, Surveying, Outdoor
Product details
| Management number | 217689878 | Release Date | 2026/04/19 | List Price | US$10.80 | Model Number | 217689878 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product Description Multi-System GNSS Antenna for High-Precision Positioning The GNSS Antenna delivers global coverage across GPS, BeiDou, GLONASS, and Galileo systems, designed for demanding applications in automotive, IoT, and industrial navigation. Specifications: Frequency Coverage: GPS: L1 (1575.42MHz), L2, L5 BeiDou: B1C, B2a, B3 GLONASS: G1, G2, G3 Galileo: E1, E5a, E5b, E6 QZSS/SBAS/IRNSS: L1/L5 bands Electrical Parameters: LNA Gain: 28±2dB Noise Figure: ≤2.0dB VSWR: ≤2.0 Impedance: 50Ω Power Supply: 3V-12V DC Mechanical & Environmental: Dimensions: 58.5x57x23.8mm Cable: RG174 (custom lengths available) Connector: SMA Male RoHS/REACH compliant Operating Temperature: -40°C to +85°C Waterproof Rating: IP65 Applications: Automotive telematics and fleet tracking UAV/drone navigation systems Marine and aviation positioning Outdoor IoT asset monitoring
- Multi-System GNSS Compatibility: Supports GPS (L1/L2/L5), BeiDou (B1C/B2a/B3), GLONASS (G1/G3), Galileo (E1/E6), QZSS, and SBAS; enables stable positioning in urban canyons, dense forests, or high-rise areas where single-system antennas may struggle for reliable navigation
- High-Gain Low-Noise Amplifier: Delivers 28 dB gain (26-30 dB range) with ≤2.0 dB noise coefficient; maintains stable signal reception in low-elevation scenarios using ≤2.0 VSWR and 4 dBi passive gain to reduce dropouts
- IP65 Waterproof & Durable Construction: ABS+PC housing with ultrasonic welding withstands harsh conditions (-40°C to +85°C, 95% humidity) and IP65-rated protection against dust and water
- Wide Voltage & Industrial Resilience: Functions on 3 V-12 V DC with ≤60 mA current; endures extreme temperatures (-40°C to +85°C) and 95% humidity for dependable use in automotive or harsh outdoor environments
- Certified Reliability: Passes 24-hour thermal cycling tests (-40°C to +85°C); meets RoHS and REACH standards to ensure long-term performance and safety compliance for professional applications
| Brand | BINGFU |
|---|---|
| Color | Black |
| Impedance | 50 Ohms |
| Unit Count | 1.0 Count |
| Manufacturer | Bingfu |
| AntennaDescription | Antenna Accessory |
| Warranty Description | Bingfu |
| Item Dimensions L x W x H | 9.1"L x 7.1"W x 0.8"H |
